The WBZ300 is a continuous stabilized soil mixing plant, primarily designed for large-scale continuous production of base stabilization materials for projects such as highways and airports. It uses a precise metering system to force-mix binders such as cement, lime, and fly ash with water to form a uniform stabilized soil mixture.
Key Parameters:
Rated Production Rate: 300 t/h
Mixing Method: Twin-Shaft Continuous Linerless Mixer
Metering System: Flow Control
Control Method: Computer-controlled / Manual Control
Applicable Materials: Cement-stabilized soil, lime-stabilized soil, and fly ash-soil.
WBZ300 Stabilized Soil Mixing Plant - An Efficient and Stable Base Material Preparation Solution
The WBZ300 Stabilized Soil Mixing Plant is a fully automatic stabilized soil mixing plant designed for the continuous production of various stabilized soil mixtures for infrastructure construction projects such as municipal highways and factory roads. With a rated capacity of 300 tons/hour, it supports a variety of mix ratios, including cement-stabilized soil, lime-stabilized soil, and sand-gravel stabilized soil, meeting the construction needs of various base materials.
- Efficient and Uniform Mixing: This equipment utilizes a twin-shaft, continuous, liner-less mixer, ensuring uniform mixing without dead spots, easy maintenance, and a long service life.
- Accurate Metering System: Aggregates, powders, and water are metered gravimetrically using flow meters.
- Fully Automatic Intelligent Control: This equipment utilizes a PLC or computer control system, enabling one-touch start and stop, automated production, fault diagnosis, and data reporting, ensuring ease of operation and high reliability.
- Modular and Eco-Friendly Design: The compact structure facilitates transportation, relocation, and installation. Wide Material Compatibility: It can process a variety of raw materials, including quicklime, hydrated lime, soil, sand and gravel, fly ash, and cement, producing cement-stabilized sand and gravel and lime-soil stabilized base materials.
This equipment is widely used for mixing base stabilization materials for urban roads, industrial sites, and other projects, making it an ideal base material mixing equipment for construction companies.
The WBZ300 Stabilized Soil Mixing Plant, with its high efficiency, high precision, high reliability, and excellent environmental performance, has become an indispensable key equipment in modern engineering construction. Its advanced control system ensures stable product quality and cost-effectiveness, helping customers improve construction efficiency and ensure project progress and quality.
Q: What is the production capacity of the WBZ300 Stabilized Soil Mixing Plant?
A: The theoretical production rate of the WBZ300 is 300 tons per hour. This equipment utilizes a continuous mixing process, enabling stable and efficient production of stabilized soil materials in various proportions, fully meeting the construction needs of various highway and municipal road projects.
Q: What mixing method does this equipment use? What is its mixing performance?
A: This equipment utilizes a twin-shaft continuous mixer. Through optimal blade arrangement and a streamlined mixing process, it ensures thorough mixing of materials during mixing, resulting in highly uniform mixing and consistently high-quality finished products.
Q: What is the required installation site area for the entire equipment?
A: The recommended installation site is at least 40 meters long and 15 meters wide (approximately 600 square meters). The specific dimensions can be optimized based on the actual configuration. We provide professional site planning guidance to ensure a rational equipment layout and efficient operation.
Q4: What is the power configuration of the equipment?
A: The total power of the entire equipment is approximately 110 kW (specific power depends on the configuration). A reasonable power distribution plan ensures production efficiency while effectively controlling energy consumption and reducing operating costs.
Q5: Is the powder metering system accurate? How is the mixing ratio accuracy guaranteed?
A: We use a high-precision spiral weighing and metering system equipped with dedicated load cells and an intelligent control system to achieve precise powder metering with an accuracy of ±1%, ensuring an accurate and reliable mixing ratio.
Q6: Is the equipment easy to move and relocate?
A: The modular design allows for quick disassembly and assembly of major components, facilitating transport. Professional lifting points significantly reduce the time and cost of equipment relocation.
Q7: Is the control system complex to operate?
A: We use a fully automatic intelligent control system with an intuitive and user-friendly interface, supporting functions such as recipe storage and data logging. We provide professional operator training, so ordinary operators can master the operating techniques in just a short period of training.
Q8: How durable are the key components of the equipment?
A: Key components such as the mixing blades and lining are made of wear-resistant alloy materials to ensure a long service life. We also provide an ample supply of spare parts to ensure continuous and stable operation of the equipment.
Q9: What kind of after-sales service do you provide?
A: We offer a 12-month warranty and lifetime technical support. We have a comprehensive after-sales service network, with professional engineers on call 24/7, ensuring that any issues encountered during equipment operation are promptly resolved.
Q10: How can I obtain detailed configuration information and a quote?
A: Please leave a message on our website or call our service hotline. Our professional technical consultants will provide you with a detailed equipment configuration plan and an accurate quote based on your specific needs within one hour.
Technical Parameters
Parameter Category | Detailed Parameters | Remarks
|
Rated Production Rate | 300 tons/hour | Core Parameter |
Concrete Mixer | Twin-shaft Continuous Mixer
| Mixer Shaft Speed: ~63.2 rpm
|
Total Installed Power | 110 kW | depending on configuration |
Number of Aggregate Silos | 3-4 | Depends on the type of raw material |
Powder Silo Capacity | 1 x 100 tons
| |
Maximum Aggregate Size | ≤60 mm
| customizable |
Discharge Height | 3.8 meters | |
Control | Automatic/Manual
|
Tongxin Machinery can provide you with a more suitable production plan based on your actual production needs and on-site conditions.
