Stabilized soil mixing station
Stabilized soil mixing plants are specialized equipment for producing stabilized soil mixtures. They precisely mix cement, lime, and other binders for a uniform blend. Widely used in infrastructure construction, such as highway bases and railway subgrades, these plants offer a high degree of automation, high mixing efficiency, and a wide range of material adaptability, making them a core component of modern road construction.
The stabilized soil mixing plant is a highly integrated mixing facility, integrating core functions such as batching, mixing, control, and finished product silo. Its compact structure, small footprint, and easy installation and relocation make it suitable for a variety of construction sites.
Main models:Â YWBZ300, YWBZ400, YWBZ500, YWBZ600
Production range:Â 300-600 tons/hour
The WBZ400 Stabilized Soil Mixing Plant is a highly efficient, continuous, automated mixing plant designed for foundation stabilization in projects such as small highways and production workshops. It uniformly mixes raw materials such as cement, lime, soil, sand, and gravel with water to form high-quality stabilized soil.
Key Parameters:
Rated Output: 400 tons/hour
Mixer Unit: Twin-shaft continuous linerless mixer
Number of aggregate silos: 3-4
Total Installed Power: Approximately 120-140 kW
Control Method: Fully Automatic PLC/Computer Control
The WBZ500 stabilized soil mixing plant adopts twin-horizontal-shaft continuous mixing technology and is equipped with an automated control system. It can efficiently mix cement, lime, soil, sand and other materials to produce highly uniform and stable base materials.
Key Parameters:
Production Capacity: 500 tons/hour
Mixer System: Linerless twin-shaft continuous mixing system
Storage Silos: 4 aggregate silos
Total Power: 155 kW
Control System: PLC/computer-controlled, fully automatic
The WBZ600 stabilized soil mixing plant utilizes advanced twin-shaft continuous mixing technology and is equipped with an automated control system. It efficiently mixes a variety of raw materials, including cement, lime, soil, sand, and gravel, producing uniform, stable, and standard-compliant roadbed materials.
Key Parameters:
Production Capacity: 600 tons/hour
Mixer: Linerless twin-shaft continuous mixer
Storage Silo Configuration: Four independent aggregate silos
Total Installed Power: 165 kW
Control Method: PLC/Computer-controlled Fully Automatic Control
The WBZ800 Stabilized Soil Mixing Plant is a large-scale, continuous-production stabilized soil mixing plant. Its core function is to uniformly mix cement, lime, fly ash, and other materials with soil, sand and gravel aggregate, and water in precise proportions to produce a stabilized soil mixture for base and subbase layers.
Key Parameters:
Production Capacity: 800 tons/hour
Mixer: Twin-shaft continuous mixer
Storage Silo Configuration: Four independent aggregate silos
Total Power: 210 kW
Control Mode: Fully Automatic
Footprint (L×W×H): Approximately 60 m x 15 m x 22 m
What is a stabilized soil mixing plant?
Stabilized soil mixing plants are specialized equipment used to produce stabilized soil mixtures for projects such as roads and airports. The following table briefly summarizes their core features:
| Features
|
Description
|
| Core Features | Continuous mixing to prepare stabilized soil mixture for base construction |
| Main types | Mobile type: with tires, flexible transfer, relatively low production capacity. Fixed type: requires a fixed foundation, high production capacity. |
| Processing materials | Cement, lime, fly ash and other binders with soil, gravel or other aggregates |
| Typical Applications | Base soil stabilization construction for high-grade highways, urban roads, squares, and airports |
| Output materials | Fly ash gravel (lime fly ash stabilized gravel), lime stabilized soil, industrial waste slag stabilized soil, etc. |
Output Materials:
Fly ash gravel (lime-fly ash stabilized crushed stone), lime-stabilized soil, and industrial waste residue-stabilized soil.
Operating Principle and Advantages: Stabilized soil mixing plants utilize a continuous forced mixing process. Aggregates (such as sand, gravel, and soil particles) and binders (such as cement and lime) are accurately weighed electronically and then fed into the mixer via a conveyor belt. Inside the mixer, the materials are thoroughly and evenly mixed, ultimately forming a low-moisture, non-fluid bulk product suitable for paving and compaction.
The key advantages of this specialized equipment include:
– Efficient and continuous operation:Â No downtime is required during production, ensuring construction progress.
– High precision and uniformity:Â A microcomputer control system and dynamic weighing technology ensure precise control of mix proportions, ensuring high mixing intensity and uniformity.
– Economical and practical:Â Long service life, low maintenance costs, and a high degree of automation significantly reduce labor costs.
Abstract
The stabilized soil mixing plant produced by Tongxin Machinery is a key equipment for modern road base construction. Through automated and continuous operations, it efficiently produces high-quality stabilized soil mixtures, which is an important guarantee for building a strong and durable road base.
Tongxin Machinery: Crafting Stabilized Soil Mixing Plants with Ingenuity | Professional Equipment Manufacturer
Configuration and manufacturer are the core variables that determine the price of stabilized soil mixing station.
Affordable Custom Concrete Equipment
Tongxin Machinery can provide you with a more suitable production plan based on your actual production needs and on-site conditions.
