The JS1500 concrete mixer has a discharge capacity of 1.5 cubic meters, strong mixing power and high efficiency. It can produce various types of concrete, including plastic, dry hard, and lightweight aggregate. It is mainly used in large-scale construction projects, hydropower hubs, road and bridge construction, and commercial concrete mixing plants.
Main Parameters:
Discharge Capacity: 1500 liters/time
Feed Capacity: 2400 liters
Mixer Motor Power: 2*30kW
Lifting Power: 18.5kW
Maximum Aggregate Size: ≤60/80 mm
The JS1500 concrete mixer is a large-capacity twin-shaft forced concrete mixer with a single-unit output of up to 1.5 cubic meters. Its excellent mixing performance and stable operation make it a core piece of equipment for various construction projects and precast concrete production.
As a representative of forced mixing technology, this unit can be used independently, combined with a PLD series batching unit to form a simple concrete batching plant, or as the main unit for an HZS75/HZS90 concrete batching plant. Its unique twin-shaft mixing system utilizes multiple sets of precisely arranged wear-resistant blades to achieve strong shear and compound rotational motion, ensuring that all types of concrete and mortar achieve extremely high uniformity in a short time, meeting high-standard construction requirements.
The unit features a heavy-duty structural design, with key components such as the mixing blades and liner constructed from high-chromium wear-resistant alloy for excellent impact and wear resistance. The innovative shaft end seal system with automatic lubrication effectively prevents mortar leakage and extends the unit's service life. The modular intelligent control system supports manual, automatic, and remote control, providing real-time monitoring of the unit's operating status to ensure safe production.
This model is equipped with a high-precision water supply system, with water metering error controlled within ±2%, ensuring precise concrete mix proportions. Multiple discharge methods, flexible discharge door opening and closing, and excellent sealing performance meet diverse operational needs. A convenient inspection window facilitates daily maintenance and replacement of wearing parts.
The JS1500 concrete mixer is primarily designed for use in large and medium-sized precast component plants, ready-mixed concrete batching plants, road and bridge construction, and water conservancy and hydropower projects, particularly for key projects with stringent concrete quality requirements. Its exceptional reliability and adaptability make it an indispensable key piece of equipment in modern concrete production.
JS1500 Concrete Mixer Technical Specifications
Parameter Category | Parameter Name | Parameter Value |
Capacity
| Discharge Capacity | 1500 liters |
Feed Capacity | 2400 liters
| |
Theoretical Production Rate | ≥ 35 cubic meters/hour | |
Power System | Mixing Motor Power | 2✖30kW |
Lift Motor Power | 18.5 kW
| |
Water Pump Power | 5.5 kW
| |
Total Power | 84 kW | |
Aggregate Specifications | Maximum Aggregate Size (Pebbles/Crushed Stone) | 80/60 mm |
Mixing System | Mixing Blade Speed | 35 rpm
|
Number of Mixing Blades | 2 x 8 (16 total)
| |
Cycle Time | Approximately 72 seconds
| |
Machine Weight: Approximately | 9,500 kg
| |
Discharge height | 3.8meters
| |
Door opening | Hydraulic/pneumatic |
